Factory assembled, balanced, single spring, stationary design cartridge seal with quench option. Suitable for crystallizing liquids or abrasive fluids encountered in the petrochemical, pulp, paper and power generation industries.

Factory assembled, balanced, single spring, stationary design cartridge seal with quench option. Suitable for crystallizing liquids or abrasive fluids encountered in the petrochemical, pulp, paper and power generation industries.

 NUTECH 4 MECHANICAL SEAL

Features and Benefits

  • Uniquely balanced for high temperature and high pressure applications.

  • O'Ring secondary seals with teflon back-up rings, elastomers supplied: kalrez, aflas, viton, EPR, nitrile, etc.

  • Flexible stationary face removes influence of centrifugal force, vibration and harmonics.

  • Seal gland incorporates flush, quench and drain. Data collection ports can be incorporated on request.



Standard Material Construction    Metal Components:  316SS   Stationary Faces:  Carbon, metalized carbon, tungsten carbide   Rotating Seats:  Silicon carbide, ceramic   Service   TYPICAL USES:  Chemicals, oil, water, abrasive slurries

Standard Material Construction

Metal Components: 316SS

Stationary Faces: Carbon, metalized carbon, tungsten carbide

Rotating Seats: Silicon carbide, ceramic

Service
TYPICAL USES: Chemicals, oil, water, abrasive slurries



Screen Shot 2018-11-28 at 8.41.43 PM.png
